Thermoplastic Housing + SUC Stainless Steel Insert Bearings
The most common solution in meat, poultry and seafood processing and packaging plants, as well as beverage, brewing and bottling plants applications, Thermoplastic bearing units are composed of the following:
Housing |
PBT / PA / PP |
Mounting holes |
304 stainless steel bushing |
Grease Fittings |
304 stainless steel |
Rings & Balls |
440 stainless steel |
Set Screw |
304 stainless steel |
Slinger & Seal Frame |
304 stainless steel |
Retainer |
304 stainless steel |
Eccentric Collar(SNA) |
304 stainless steel |
Seal & O ring |
Nitrile & Silicone Rubber |
Lubrication |
Mobil FM222 NSF H1 food grade grease |
Operating Temp. |
-10° F to 250° F (-20° C +120° C ) |
The most common solution in bacterial may grow in foodstuff like E-coli, Salmonella etc. Waterproof plastic bearing units are composed of the following:
Housing |
PBT / PA / PP solid base |
Mounting holes |
304 stainless steel Bushing |
Protection caps |
PP with anti-bacteria protection |
Grease Fittings |
304 stainless steel |
Rings & Balls |
440 stainless steel |
Set Screw |
304 stainless steel |
Slinger & Seal Frame |
304 stainless steel |
Retainer |
304 stainless steel |
Eccentric Collar(SNA) |
304 stainless steel |
Seal |
Nitrile & Silicone Rubber |
Lubrication |
Mobil FM222 NSF H1 food grade grease |
Operating Temp. |
-10° F to 250° F (-20° C +120° C ) |
Anti-Bacteria Plastic Bearing Units
The most common solution in bacterial may grow in foodstuff like E-coli, Salmonella etc. Waterproof plastic bearing units are composed of the following:
Housing |
PBT / PA / PP solid base |
Mounting holes |
304 stainless steel Bushing |
Protection caps |
PP with anti-bacteria protection |
Grease Fittings |
304 stainless steel |
Rings & Balls |
440 stainless steel |
Set Screw |
304 stainless steel |
Slinger & Seal Frame |
304 stainless steel |
Retainer |
304 stainless steel |
Eccentric Collar(SNA) |
304 stainless steel |
Seal |
Nitrile & Silicone Rubber |
Lubrication |
Mobil FM222 NSF H1 food grade grease |
Operating Temp. |
-10° F to 250° F (-20° C +120° C ) |
Application
Food processing machinery Medical equipment Chemical and Agricultural machinery
Meat, poultry and seafood processing and packaging plants, as well as beverage, brewing and bottling plants.
-
